NOVO Moinho de Tambor TM 500 Dados Técnicos
| Applications: | pulverizing, mixing, dry grinding |
|---|---|
| Field of application: | agriculture, biology, chemistry, construction materials, engineering / electronics, environment / recycling, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals |
| Feed material: | soft, hard, brittle, fibrous |
| Size reduction principle: | friction, impact |
| Final fineness: | < 15 µm |
| Batch size / feed quantity: | min. 1 l / max. 35 l |
| Rotation speed: | 10 - 50 min-1 |
| No. of grinding stations: | 1 |
| Material of grinding tools: | hardened steel, stainless steel, steel 316L |
| Grinding drum sizes: | 150 l |
| Setting of grinding time: | digital, 00:00:01 to 99:59:59 |
| Drive: | 3-phase asynchronous motor with frequency converter |
| Drive power: | 2.2 kW |
| Electrical supply data: | 200-240 V, 50/60 Hz |
| Power connection: | 1-phase |
| Power consumption: | ~ 2200 W (VA) |
| Protection code: | IP 30 |
| W x H x D closed: | 1100 x 1604 x 936 mm |
| Net weight: | ~ 460 kg |
| Standards: | CE |
NOVO Moinho de Tambor TM 500 Downloads
Termék adatlap TM 500
Three rules for the optimium ball setup
The success of a ball milling application depends on the correct selection of accessories and process parameters. This includes jar sizes, jar materials, ball sizes, number of balls, particle size, material fill level, speed and time or cycle programs. Finding the optimum setup is a challenging task because the result depends on the motion of the balls inside the jar, which is inherently statistical and chaotic in nature.
