EasySieve pro / EasySieve pharma Характеристики
| System requirements: | Windows 11 or higher |
|---|---|
| Computer: | IBM compatible PC |
| CPU: | 1.6 GHz or more, Multicore (recommended Intel i7 or comparable) |
| RAM: | 4 GB minimum (8 GB recommended) |
| Connections: | min. 2 x USB 2.0 (sieving machine, balance) |
| HDD: | 256 GB |
| Display resolution: | 1920 x 1080 |
| Graphical User Interface, guided sieving: | Yes |
| Languages: | German and English |
| Parameter units changeable: | size in mm/µm/mesh/inch mass in g/kg time in s/min |
| SOPs: | Yes, integrated in methods |
| Individual sample labelling: | Yes, for each sample, reference to method during data choice and in overview |
| Parameter setting per test sieve: | Yes |
| LIMS ready: | yes |
| Teamviewer online support: | Yes |
| Screenshot function: | yes |
| Back-up function: | Yes |
| Automatic storage of results: | Yes |
| Results shown, as table or graphs: | Yes |
| Data export: | Yes: *.xls, *.xlsx, *.xps, *.csv, *.pdf, *.png, *.jpg, *.txt, *.rtf, *.html, *.mht |
| Different diagram types (linear or logar.): | Yes, log/lin, log/log, lin/lin for x and y axis |
| Different diagram types: | Cumulative, RRSB, Histogram, density, residual distribution |
| Calculation of individual dx values: | More than 10 |
| Label naming: | ISO (q3/Q3/1-Q3/p3) or descriptive (density/total distribution/residual distribution/percent) |
| Overlay of results: | Yes, up to 32 Curves, tables and overview |
| Individual scalable diagrams: | Yes, via zoom in or via setting of max. axis value |
| Highest precision thanks to: | Sieve-Check function, Weighing-Assistant and Weigh-in tolerance, Filter function for sieve rows, TrendAnalysis for sieves and methods, Backweighing-Tolerance |
| Connection to sieving machines: | Yes, AS 200 control B (USB, from year of manufacture 2016), AS 200 jet (USB), AS 200 tap (RS232), AS 300 control B (USB, from year of manufacture 2016), AS 400 control (RS232), AS 450 control (RS232) |
| Connection of external balance: | Yes, RS232-communication via USB |
| Standard balance driver: | Yes, scale management for external scales, communication protocols for specific scales Kern, Sartorius, Mettler are stored. |
Additional features EasySieve pharma Характеристики
| Software validation: | ISPE GAMP 5, EC GMP Annex 11 conform, AuditTrail acc. to FDA 21 CFR part 11 |
|---|---|
| User management: | Yes, free configurable levels, individual rights option for each user |
| Role and password management: | Yes |
| Audit-trail with E-signature: | Yes |
| Enforce audit trail comments: | yes |
| Generation/Export of user lists and daily reports: | Yes |
| Restore: | Yes |
EasySieve / EasySieve CFR Программное обеспечение Скачать
Паспорт изделия Easy Sieve
Скачать
pdf Pусский (~1 MB)
pdf Английский (~1 MB)
pdf Болгарский (~1 MB)
pdf Японский (~1 MB)
pdf Испанский (~1 MB)
pdf Чешский (~1 MB)
pdf Голландский (~1 MB)
pdf Немецкий (~1 MB)
pdf Португальский (~1 MB)
pdf Китайский (~2 MB)
pdf Норвежский (~1 MB)
pdf Венгерский (~1 MB)
pdf Корейский (~1 MB)
pdf Итальянский (~1 MB)
pdf Румынский (~1 MB)
pdf Французский (~1 MB)
pdf Турецкий (~1 MB)
pdf Польский (~1 MB)
pdf Словацкий (~1 MB)
General Catalogue
Product Overview
White Paper. Different sieving methods for a variety of applications
The determination and knowledge of the particle size distribution is an essential part of the quality control process for industrial products. Easy handling, low investment cost and high accuracy make sieve analysis one of the most frequently used procedures for measuring the particle size. This white paper gives an overview of the different sieving techniques and describes the necessary steps to ensure reliable results.
