Hammer Mill HM 200 Teknik Veri
| Applications: | coarse and pre-crushing, desagglomeration |
|---|---|
| Field of application: | agriculture, geology / metallurgy, glass / ceramics, coal, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food / feed |
| Feed material: | medium-hard, hard, brittle, tough, fibrous |
| Size reduction principle: | impact, shearing |
| Max. feed size: | < 100 mm |
| Final fineness: | < 0.8 mm |
| Batch size / feed quantity: | up to 30 l depending on collecting receptacle |
| Speed at 50 Hz (60 Hz): | 3000 min-1 (3500 min-1) |
| Throughput: | 1500 kg/h |
| Rotor peripheral speed: | 31.4 m/s |
| Rotor diameter: | 200 mm |
| Types of rotors: | 10 swing hammer |
| Dry grinding: | yes |
| Wet grinding: | no |
| Cryogenic grinding: | no |
| Material of grinding tools: | hardened steel 1.0503 (hammers); steel 1.0330 (sieves) |
| Sieve sizes: | 2 / 3 / 4 / 5 / 6 / 8 / 10 / 15 / 40 mm |
| Dust extraction unit: | yes |
| Process line version: | yes |
| Collector capacity: | 10 l, 30 l, continuous outlet |
| Drive: | 3-phase motor |
| Drive power: | 1.5 kW |
| Electrical supply data: | different voltages |
| Power connection: | 3-phase |
| Protection code: | IP 54 |
| W x H x D closed: | 700 x 1570 x 750 mm |
| Net weight: | ~ 150 kg |
| Standards: | CE |
