滚筒式研磨仪TM 300 技术参数
| Applications: | pulverizing, mixing used as Bond Index Tester: quantification of grindability of ores and minerals |
|---|---|
| Field of application: | agriculture, biology, chemistry, construction materials, engineering / electronics, environment / recycling, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals |
| Feed material: | soft, hard, brittle, fibrous - dry or wet |
| Size reduction principle: | friction |
| Final fineness: | < 20 µm used as Bond Index Tester: < 100 µm with ball module / 2,100 µm with rod module |
| Batch size / feed quantity: | minimum 1 l / maximum 20 l used as Bond Index Tester: min. 15 kg with ball module / min. 20 kg with rod module |
| Rotation speed: | 1 - 80 min-1 used as Bond Index Tester: 70 min-1 with ball module / 46 min-1 with rod module |
| No. of grinding stations: | 1 |
| Material of grinding tools: | hardened steel, stainless steel used as Bond Index Tester: hardened steel |
| Grinding drum sizes: | 5 l / 10 l / 21.7 l / 43.3 l used as Bond Index Tester: 21.7 l with ball module / 43.3 l with rod module |
| Setting of grinding time: | digital |
| Drive: | 3-phase asynchronous motor with frequency converter |
| Drive power: | 0.75 kW |
| Electrical supply data: | different voltages |
| Power connection: | 1-phase |
| Power consumption: | ~ 1800 VA |
| Protection code: | IP 41 |
| W x H x D closed: | 1500 x 1200 x 700 mm |
| Net weight: | ~ 306 kg |
| Standards: | CE |
滚筒式研磨仪TM 300 资料下载
General Catalogue
Green Cement - Innovation in the Construction Industry
Green Cement represents a significant innovation in the construction industry, aimed at reducing environmental impact and promoting sustainable development. Traditional cement production is a major contributor to global CO emissions, accounting for approximately 7-8% of the total. With this material these emissions can be minimized by incorporating supplementary cementitious materials (SCMs) such as fly ash, slag and seashell by using alternative fuels and raw materials. Our solutions enable the production of a more sustainable product with high performance characteristics and exceptional physical properties.
Product data sheet TM 300
下载
pdf 英语 (~1 MB)
